Approval of model under the Legal Metrology Government of India

Multi Head Weigher Type Vertical Form & Sealing Machine

The FASTEX Fully Automatic collar type Vertical from fill & sealing machine with multi-head weigher filler High Speed & High Precision Weighing is the uniqueness FASTEX series is well known for its pouch finish & sealing intactness which prevents leakage of inert gas from pouches & gives extended product sheif life.

Technical Specifications

Machine Name BBP - 23 A
Packing Range 10gm to 1kg
Filling Accuracy 0.5 - 1% (Depend on nature of Product)
Filling System (Multi Head Weigher) 10. 14 &16 Head
Film Size 100mm-500mm width x 100mm-300mm length
Film Roll Type Heat Sealable Laminated Film
Speed 45 to 60 bag/min (Varies with the nature of product & filling range)
Power 3kw 230v / AC / Single Phase / 50hz
Air Compressed
 6 CFM @ 6 bar
Machine Size L:2300mm x W:1200mm x H:2800mm(Aprox.)
Weight 2000. kg (Approx)
Optional Batch Coding Device, Batch Cutting Device, Auto Lubrication, Gas Flushing,

Application

The packing machine are suitable for all kinds of grains and solids, like candies, nuts, raisins, peanuts, melon seeds, nuts, potato chips, chocolate, biscuits, and more.

New Functions

  • FASTEX packing machine provide low cost high gain, high speed and efficiency.
  • Both of the vertical form fill seal (VFFS) machines come with famous brand PLC control system and large touch screen, and are thus easy to operate.
  • The vertical packaging machine makes use of film drawing down system and horizontal sealing controlled by servo motor/Pnuematic.
  • Mulit Language Menu in one touch screen
  • All food contacted surface is made of Stainless Steel,all parts are enclosed to prevent product build-up.Waterproof and dustproof construction
  • Speed adjustment of hopper movement by steppermotor,no air consumption
  • High accuracy load cell for weight calculation
  • Automatic opening/closing weigh bucket speed adjustment - minimizes product damage
  • Stainless steel product contact points
  • 50 program product memory
  • As to the way of bag making, the VFFS machine can make pillow type bags and standup bags asper customer needs.
