Approval of model under the Legal Metrology Government of India

Auger Filler Type Vertical Form Fill & Sealing Machine

Technical Specifications

Machine name VFFS. Collar Type Sarvo Augar Machine
Model BPP - 01
Filling Capacity 50 - 250 to 500 - 1000. Gms.
Weighing Speed 1000 to 4000 Pouches / Hr.
Total Power 2.5 Kw. 220v. Single Phase 50 / 60Hz,
Air Compresser 8 Cfm With 6 bar Pressure
Weight 700 Kg (Approx)
Dimension 1250mm X 1200mm X 1800mm (D x W x H)

Application

The FASTEX VFFS (Vertical Form Fill Seal) Collar Type Sarvo Augar Machine suits all kinds of powder, like milk powder, coffee, spices, additives, and more.

Main Features

  • FASTEX VFFS machine provides low cost high gain, high speed and efficiency.
  • The powder vertical form fill seal machine comes with famous brand PLC control system and large TOUCH SCREEN, and thus is easy to operate.
  • The vertical packaging machine makes use of film drawing down system and horizontal sealing controlled by servo motor. & Pneumatic
  • The powder VFFS machine minimizes the loss, by use of auto alarm design.
  • Equipped with feeding and measuring devices, the packing machine accomplishes feeding, measuring, filling, sealing, date printing, charging (exhausting), counting, and finished product delivery, in a continuous flow.
  • As to the way of bag making, the vertical form fill seal machine can make pillow type bags and standup bags as per customer needs.

Auger Filler Type Vertical Form Fill & Sealing Machine

Technical Specifications

Machine name Half Pneumatic Sarvo Augar Fillers
Model BPP - 021
Filling Capacity 25 to 1000 Gms.
Weighing Speed 1000 to 3000 Pouches / Hr.
Total Power 2 Kw. 220v. Single Phase 50 / 60Hz,
Air Compresser 5 Cfm With 6 bar Pressure
Weight 550 Kg
Dimension 1120mm X 880mm X 2380mm ( D x W x H )

Application

The FASTEX powder VFFS Augar ( vertical Form Fill Seal) machine suits all kinds of powder, like milk powder, coffee, spices, additives, and more.
